X-CM105C
Pneumatic IDC cable crimping machine flat cable crimping machine
Ribbon cable connector crimping machine

Feature
1.Special for crimping 4-64P IDC flat cable connector instead of hand pressure pliers.
2.Low gas consumption, low failure rate, easy maintenance.
3.With the use of bakelite base, simple operation, wear resistance, high precision.
4.Applicable to IDC connector cirmping flat cable.
5.After the product is pushed into the automatic stamping, after the cylinder reset. Easy to learn

Function: Ribbon cable crimping
Name:IDC cable crimping machine flat cable crimping machine
Air pressure: 6-8KG
Voltage: 110V/220V
Speed: 6000 Times/h
Weight: 20KG
Dimension: 250*200*330mm
wire range: 4-40P one fixture,40-64P one fixture
Packing: Plywood
Warranty: 1 Year
